Food Grade Stainless Steel Homebrew Equipment , Wine Fermentation Tanks

 CGET, factory with over 20 years brewery equipment manufacturing history.

wine tank, winery equipment,

craft beer brewery plant with all accessories: standard 6 fermenters, 2 bright beer tanks

microbrewery turnkey brewery complete brewery whole plant, fitted in one 40HQ container

for all size brewpub with all scale fermentation tank, conical tank, pressurized

bright beer tank for maturation, jacketed, glycol cooling, stainless steel

Specifications for 1000L bright beer tank/ storage tank:

1. Total volume: 1330L,effective volume:1000L;

2. Size Φ1160×2500mm

3. Heat exchange area: 3.1㎡;

4. Racking Arm and discharge port with butterfly valve and fittings;

5. PLC control, dimple plate cooling jacket.

6. Insulation thickness: 80mm; Inner tank thickness : 4mm;

7. CIP arm and spray ball

8. Release and breath valves

9. Side manway

10. Pressure gauge & Thermometer & Sample valve.

11. Two zone dimple cooling jacket with glycol inlet and outlet;

12. Four legs with brace and adjustable bolt;

13. Interior of tank is mechanical polished, inner body polishing ratio ≦0.6μm. Out plate surface brush finished.

14. With valves and accessories matched.

15. Tank cone angle 140°
