Large Stainless Steel Brewing Equipment Stainless Fermentation Vessel

CGET, A professional manufacture of brewing equipment for 20-year history

Large Stainless Steel Brewing Equipment Stainless Fermentation Vessel

microbrewery turnkey brewery complete brewery whole plant, fitted in one 40HQ container

all size Fermentation tank, conical tank, pressurized, 3.5bbl, 5bbl, 7bbl, 10bbl, 15bbl, 20bbl, 30bbl.

bright beer tank for maturation, jacketed, glycol cooling, stainless steel

For example, a standard 2000L fermentation tank specifications is as follows:

1. Total volume: 2550L,effective volume:2000L;

2. Size Φ1600×3090mm

3. Heat exchange area: 3.6㎡;

4. Racking Arm and discharge port with butterfly valve and fittings;

5. PLC control, dimple plate cooling jacket.

6. Insulation thickness: 80mm; Inner tank thickness: 3mm;

7. CIP arm and spray ball

8. Release and breath valves

9. Side manway

10. Pressure gauge & Thermometer & Sample valve.

11. Two zone dimple cooling jacket with glycol inlet and outlet;

12. Four legs with brace and adjustable bolt;

13. Interior of tank is mechanical polished, inner body polishing ratio ≦0.6μm. Out plate surface brush finished.

14. With valves and accessories matched.

15. Tank cone angle 60°
