Stainless Steel 304 Craft Beer Making Equipment 100L 200L 300L 500L 1000L Per Batch
1. Two vessels, three vessels, four vessels brewhouse available
2. Different specifications meet different needs of customers
3. Mash tank; hydrator, mixer, steam heating jacket
4. Lauter tun: rake, agitator, false bottom, hydrator
5. Brewkettle, steam heating jacket, inner steam heating deivce; direct fire
6. Whirlpool tun: whirlpool entry
7. Pumps, processing piping, valves and fittings
Mill system
80kg/h, 100kg/h, 200kg/h, 300kg/h, 500kg/h, 1000kg/h
Beer brewing system’s analysis
| items | CG-0.1 | CG -0.2 | CG -0.3 | CG-0.5 | CG -1.0 | CG -2.0 |
| Production capacity | 100L/day | 200L/day | 300L/day | 500L/day | 1000L/day | 2000L/day |
| floor space | 15m2 | 25m2 | 35m2 | 50m2 | 80m2 | 120m2 |
| Total power | 12kw | 12kw | 12kw | 15/36kw | 22/72kw | 31/144kw |
| Maximum hourly water consumption | 0.2m3/h | 0.4m3/h | 0.5m3/h | 1.0m3/h | 1.5m3/h | 2.0m3/h |
| Total water used | 0.5m3/d | 1.m3/d | 1.5m3/d | 2.5m3/d | 5m3/d | 10m3/d |
| Consumption of malt | 20kg | 40kg | 60kg | 100kg | 200kg | 400kg |
| Consumption of hops | 60g | 120g | 180g | 300g | 600g | 1.2kg |
| Yeast | 100g/1L | 200g/2L | 300g/3L | 500g/5L | 1kg/10L | 2kg/20L |
| Maximum steam | 0.017t/hour | 0.017t/hour | 0.05t/hour | 0.10t/hour | 0.20t/hour |
1. All tanks will be packaged with soft protection material and mounted on strong carbon steel frame
2. All accessories and spare parts will be packaged with seperated box.
3. After loaded into containers, all equipments will be well fixed to the containers.
About US
Kelang company ,founded in 1997,is a service-outsourcing and new high-tech enterprise in fermentation engineering industry,Provide the customers with systemic solution of non-standard technical renewal on the fermentation field,is committed to the first person on the fermentation service outsourcing field.
Company provides fermentation project technology service to enterprises in the area of Alcohol, condiment, biopharmacy and any other bio-fermenting lines.Service is including technology proposal design,a complete set of equipment,application project installation,training technicians,financing service etc five system links.
Our products have been exported to many countries in the world,and our company has established long-term and friendly cooperative relations with Russia, the United States, Canada, Britain, Australia, New Zealand, Kenya, Moldova, Israel, Singapore, Philippines, India, Holland and many other countries and regions,awarding high praise from our customers.
